HI-3110PSHF
HI-3110Series Standalone CAN Controller IC
The HI-3110H is a standalone Controller Area Network (CAN) controller with built in transceiver optimized for use in high temperature avionics applications. The device is capable of operating at extended temperature ranges of -55?C to 175?C and provides a complete, integrated, cost-effective solution for high temperature avionics applications implementing the CAN 2.0B specification. It can be configured to comply with both the ARINC 825 (General Standardization of CAN Bus Protocol for Airborne Use) and CANaerospace standards. The HI-3110H is capable of transmitting and receiving standard data frames, extended data frames and remote frames. The internal transceiver allows direct connection to the CAN bus without using external components and coupled with the host Serial Peripheral Interface (SPI), results in minimal board space.
Key Features
- Implements CAN version 2.0B with programmable bit rate up to 1Mbit/sec. ISO 11898-5 compliant.
- Extended Temperature Range -55°C to 175°C.
- Configurable to support ARINC 825 and CANaerospace Standards.
- Filtering on ID and first two data bytes for both Standard and Extended Identifiers.
- Permanent dominant timeout protection.
- Serial Peripheral Interface (SPI) (20MHz).
- Standard, Extended and Remote frames supported.
- 8 maskable identifier filters.
- Loopback mode for self-test.
- Monitor (Listen-only) and Low Power Sleep Modes with automatic wake-up possible.
- 8-message Transmit and Receive FIFOs.
- Internal 16-bit free running counter for time tagging of transmitted or received messages.
- Short Circuit Protection of -58V to + 58V on CAN_H, CAN_L and SPLIT pins (ISO 11898-5).
- Re-transmission disable capability.
- Transmit Enable pin.
]
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Temperature Range | -55°C to +175°C |
|---|---|
| RoHS | Yes |
| Applications |
|
| Flow | H |
| Moisture Sensitivity Level | 3 |
| Package Description | 18 Pin Plastic SOIC - WB |
| Product Longevity | > 10 years |
| Theta JA C W | 26.16 |
| Theta JB C W | 15.07 |
