Holt Integrated Circuits
HI-3185PST
SKU: HI-3185PST
HI-3185 Series Line Driver
The HI-3182, HI-3183, HI-3184, HI-3185, HI-3186, and HI-3188 bus interface products are silicon gate CMOS devices designed as a line driver in accordance with the ARINC 429 bus specifications. In addition to being functional upgrades of Holt’s HI-8382 & HI-8383 products, they are also alternate sources for the HS-3182 ( Intersil/Harris), the RM3182 (Fairchild /Raytheon) and a variety of similar DEI/DDC line driver products.
Key Features
- Low Power CMOS
- TTL and CMOS Compatible Inputs
- Programmable Output Voltage Swing
- Adjustable ARINC Rise and Fall Times
- Plastic 14 & 16-Pin Thermally Enhanced SOIC Packages Available
- Pin-for-Pin Alternative For DEI/DDC/Intersil/Fairchild Applications
- Operates At Data Rates Up To 100 Kbits
- Overvoltage Protection
- Industrial & Extended Temperature Ranges Available
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Temperature Range | -55°C to +125°C |
|---|---|
| RoHS | No |
| Applications |
|
| Flow | T |
| Moisture Sensitivity Level | 1 |
| Package Description | 14 Pin Plastic ESOIC - NB |
| Theta JA C W | 31.39 |
Downloads
| Datasheet | Click to view Datasheet (PDF) |
|---|
