HI-62025PQI
HI-62025 Series MIL-STD-1553 fully integrated dual redundant interface IC
The HI-62023 family is a fully integrated and dual redundant MIL-STD-1553 Remote Terminal interface solution which includes 1553 protocol, SRAM and dual transceivers in single 80-pin plastic PQFP and QFN package configurations. The devices are software compatible with the Data Device Corporation (DDC?) Mini-ACE?, Enhanced Mini-ACE?, Micro-ACE?, Mini-ACE? Mark3 and Total-ACE? families of MIL-STD-1553 Terminals and offer additional features such as Error-Correcting Code (ECC) SRAM. The compact single-chip monolithic design offers a significant space and cost saving over the older traditional multi-chip module approach.?An improved and simplified high-performance 16-bit host interface provides faster access time to the Shared RAM, significantly reducing latency and CPU utilization. The on-chip ECC RAM provides additional protection against data corruption by automatically detecting and correcting memory errors.
Key Features
- Dual Redundant MIL-STD-1553A/B/1760 Channel
- 64Kx16 ECC SRAM
- External RT Address Inputs
- MIL-STD-1760 RT “Auto Boot”
- +3.3V single supply operation
- Built-in Self-Test
- Generic 8/16-bit Processor Interface
- -40°C to +85°C or -55°C to +125°C
- No Limitations on transmit duty cycle
- 80-Pin PQFP package
- 12mm x 12mm x 1.6mm
- 80-Pin QFN package
- 12mm x 12mm x 0.8mm
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Temperature Range | -40°C to +85°C |
|---|---|
| RoHS | No |
| Applications |
|
| Flow | I |
| Moisture Sensitivity Level | 3 |
| Package Description | 80 Pin Plastic Quad Flat Pack (LQFP) |
| Product Longevity | > 10 years |
| Theta JA C W | 23 |
| Theta JB C W | 13.71 |
