Holt Integrated Circuits
HI-62605CQIF
SKU: HI-62605CQIF
HI-62605 Series MIL-STD-1553 Simple System Remote Terminal
The HI-6260xCx family is a fully integrated and dual redundant MIL-STD-1553 Simple System Remote Terminal (SSRT) solution which includes 1553 protocol and dual transceivers in a single package. The device is a direct pin compatible drop-in replacement for the Data Device Corporation (DDC?) Mini-ACE? Mark3 SSRT family of MIL-STD-1553 Terminals.
Key Features
- Fully Integrated Remote Terminal including dual 3.5V or 5V transceivers
- MIL-STD-1553A/B/1760 Compliant
- 32-Word Internal FIFO with burst mode capability
- 16-Bit DMA Interface
- External RT Address Inputs
- Built-in Self-Test
- Auto-Configuration Capability
- -40°C to +85°C or -55°C to +125°C
- 80-Pin Hermetic Gull Wing Package
- 22.4mm x 22.4mm x 3.6mm
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Temperature Range | -40°C to +85°C |
|---|---|
| RoHS | Yes |
| Applications |
|
| Burn In | No |
| Flow | I |
| Package Description | 80-Pin Hermetic Gull Wing Package |
| Product Longevity | > 10 years |
| Theta JA C W | 30.73 |
| Theta JB C W | 13.84 |
Downloads
| Datasheet | Click to view Datasheet (PDF) |
|---|
