Holt Integrated Circuits
HI-8040QM-01
SKU: HI-8040QM-01
HI-8040 Series LCD Display Driver IC
The HI-8040 is a CMOS integrated circuit designed for high voltage LCD display drive applications. It can drive 85 segments at voltages between +5 and -30 volts. An optional negative converter can generate the negative display drive voltage. Test inputs facilitate opens and shorts testing. The backplane frequency is checked and, as long as power is available, the segments are shut “OFF” if the frequency becomes too low.
Key Features
- 4 MHz serial input data rate
- 85 segment outputs
- Cascadable
- 5 Volt inputs translated to 35 Volts
- Test pins allow hardware all
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Temperature Range | -55°C to +125°C |
|---|---|
| RoHS | No |
| Applications |
|
| Burn In | Yes |
| Flow | M |
| Package Description | 100-Pin Ceramic QFP |
| Product Longevity | > 10 years |
Downloads
| Datasheet | Click to view Datasheet (PDF) |
|---|
