Holt Integrated Circuits
HI-8483PSI
SKU: HI-8483PSI
HI-8483 Series ARINC 429 Line Receiver
The HI-8483 bus interface unit is a dual differential line receiver in accordance with the requirements of the ARINC 429 bus specification. The device translates incoming ARINC 429 signals to normal CMOS/TTL levels on each of its two independent receive channels. The HI-8483 is a functional alternative to the Fairchild/Raytheon RM3283 and DEI3283.
Key Features
- Replacement for RM3283 and DEI3283
- Converts ARINC 429 Levels to Digital Data
- Input Hysteresis for Superior Noise Rejection
- TTL and CMOS Outputs and Test Inputs
- Industrial & Extended Temperature Ranges Available
- 20-Pin SOIC, DIP & LCC Packages Are Available
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Temperature Range | -40°C to +85°C |
|---|---|
| RoHS | No |
| Applications |
|
| Flow | I |
| Moisture Sensitivity Level | 3 |
| Package Description | 20 Pin Plastic SOIC - WB |
| Product Longevity | > 10 years |
| Theta JA C W | 90 |
Downloads
| Datasheet | Click to view Datasheet (PDF) |
|---|
