Holt Integrated Circuits
HI-8588PDTF-10
SKU: HI-8588PDTF-10
HI-8588 Series ARINC 429 Line Receiver
The HI-8588-10 ARINC 429 bus interface receiver is similar to the HI-8588 with the exception that it allows an external 10 Kohm resistor in series with each ARINC input without affecting the ARINC input thresholds. The product is especially useful in applications where lightning protection circuitry is also required. In addition, the test inputs force both of the outputs to zero instead open circuit. This analog/digital CMOS product requires only a 5 volt supply and is available in a SO 8 pin package.
Key Features
- ARINC 429 Line Receiver Interface in a Small Outline Package
- Lightning Protection Simplified With the Ability to Add 10 Kohm External Series Resistors
- Receiver Input Hysteresis at Least 2 Volts
- Test Inputs Bypass Analog Inputs and Force Digital Outputs to a One, Zero or State
- Plastic and Ceramic Package Options - Surface Mount and DIP
- Industrial & Extended Temperature Ranges Available
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Temperature Range | -55°C to +125°C |
|---|---|
| RoHS | Yes |
| Applications |
|
| Flow | T |
| Moisture Sensitivity Level | 1 |
| Package Description | 8 Pin Plastic DIP |
| Product Longevity | > 10 years |
| Theta JA C W | 57.06 |
Downloads
| Datasheet | Click to view Datasheet (PDF) |
|---|
