Meinberg
VP100/20NET
SKU: VP100/20NET
Large NTP Display
Large display and NTP slave clock VP100/20 with good visibility and 50mm height LED characters. Text messages can be displayed: fixed, flashing or running characters, programmable via PC.
Key Features
NTP Slave Clock
20 mA Interface
50mm LED Display for Time and Date
RS-232 interface
Message Editor for Windows Operating Systems
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Dimensions | 996mm x 100mm x 60mm ( width x height x depth) |
|---|---|
| Operating Temperature | 0 ... 50°C / 32 ... 122°F |
| RoHS | Yes |
| IP Rating | IP30 |
| Form Factor | Plastic coated steel sheet case, black (optional: white) |
| Interface | One serial RS232/20mA interface |
| Power Supply | 85-264VAC (50/60Hz) / 120-375VDC |
| Backup Battery Type | In case of supply voltage failure the on-board RTC keeps the time based on XTAL for more than 100 hours |
| Data Format of Interfaces | Baudrate: 9600 Baud
Dataformat: 7E2 1 active/passive 20mA current loop output (selectable) 1 active/passive 20mA current loop input (selectable) Output string: 32 ASCII characters with date, time and status information |
| Electrical Connectors | 3 x 25-pin DSub female connector: PC IN, IN: Auxiliary inputs - for servicing purposes only OUT: Output for the time and message telegrams 9-pin DSub female: Relay: Terminal Network, RJ-45 230 V: Euro Socket for mains connections |
| Output Display Type | LED-Matrix Display (7 dots high) for time and date 50mm character height Without RF signal the clock runs on XTAL with an accuracy of ±1·10-5, indicated by LED |
| Relative Humidity | Max. 85% |
| Scope of Supply | VP100/20 LE-Display, printed manual, power cord and angle brackets for wall mounting (for a vertically swivelling display). |
| WEEE Status of the Product | This product is handled as a B2B category product. In order to secure a WEEE compliant waste disposal it has to be returned to the manufacturer. Any transportation expenses for returning this product (at its end of life) have to be incurred by the end use |
