Meinberg
IMS-VSG
SKU: IMS-VSG
Audio/Video-Sync Generator
The IMS-VSG181 is used as a video signal reference for studio equipment and provides the generated signals at four BNC outputs. These are Bi-Level Sync (Black Burst) / Tri-Level-Sync, Longitudinal Time and Control Code (LTC), Digital Audio Out (DARS), and Word Clock.
Key Features
Four BNC outputs with configurable video and audio signals:
- Out 1: Black Burst (PAL, NTSC with VITC support), tri-level sync
- Out 2: LTC 25 fps, 23,98 fps, 29,97 fps, 29,97 fps Drop Frame
- Out 3: DARS (Digital Audio Reference System)
- Out 4: Word Clock
- Four LEDs: Signal status of module and outputs
Supported video formats:
- PAL (SMPTE259M/ITU-R BT.470-6)
- NTSC (SMPTE170M/ITU-R BT.470-7)
- VITC (SMPTE12M-1/SMPTE ST309M)
- 720p50 Hz (SMPTE296M3)
- 1080i25 Hz (SMPTE274M6)
- 720p59,94 Hz (SMPTE296M1)
- 1080i29,97 Hz (SMPTE274M7)
Supported time code formats:
- LTC - Linear Time Code (25 fps, 23,98 fps, 29,97 fps, 29,97 fps Drop Frame)
- Digital Audio Reference Signal (DARS):
- Resolution: 24bits
- Base frequencies - 44,1 kHz and 48 kHz
Word Clock rates:
- Frequency range - 24 Hz - 12.288 MHz
Need help selecting the right solution?
Our technical specialists can help you choose the right product, answer technical questions and provide a quotation.
Technical Specifications
| Operating Temperature | 1 ... 50°C / 32 ... 122°F |
|---|---|
| RoHS | Yes |
| BNC Connectors | Out 1:
Black Burst Output Output signal: PAL, NTSC Black Burst with VITC support Signal level: 300 mVpp into 75 Ohm (unbalanced) PAL (SMPTE259M/ITU-R BT.470-6) NTSC (SMPTE170M/ITU-R BT.470-7) VITC (SMPTE12M-1/SMPTE ST309M) Tri-Level Sync: 720p50 Hz (SMPTE296M3) 1080i25 Hz (SMPTE274M6) 720p59,94 Hz (SMPTE296M1) 1080i29,97 Hz (SMPTE274M7) Out 2: LTC output Signal: LTC (25 fps, 23,98 fps, 29,97 fps, 29,97 fps Drop Frame) Signal level: TTL, 2.5 Vpp (MARK/SPACE) into 75 Ohm Out 3: DARS output Output signal: DARS Signal level: TTL, 2.5 Vpp into 75 Ohm Signal type: base frequencies - 44.1 kHz and 48 kHz Out 4: Word Clock output Output signal: Word Clock Signal level: TTL, 2,5 Vpp into 75 Ohm Frequency range: 24 Hz - 12,288 MHz Base frequencies: 44.1 kHz and 48 kHz Scale factor: 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64, 128, 256 |
| Current Consumption | 5 V ± 5%, 250 mA |
| Electrical Connectors | 96-pin VG-rail DIN 41612 |
| Further Information | Functionality
The VSG181 is Synchronised by an external 10 MHz signal, 1PPS and a time telegram, which provides the connected reference receiver. These signals significantly determine the accuracy of the output signals. The generated video signals, in different formats, have a phase reference to the 1PPS. In order to be able to provide high-precision output signals during the switchover of the RSC (IMS systems with redundant receivers), the VSG181 has its own oscillator. |
| Relative Humidity | Max. 85% |
| Status Info | St: Status of VSG181
|
| WEEE Status of the Product | This product is handled as a B2B category product. In order to secure a WEEE compliant waste disposal it has to be returned to the manufacturer. Any transportation expenses for returning this product (at its end of life) have to be incurred by the end user, whereas Meinberg will bear the costs for the waste disposal itself. |
